Yaegoo Belay Rigging System Hardware Kit for 5:1 Mechanical Advantage Pulley/Hauling/Dragging System

Large Rescue Pulley Double Sheave:
-Color: Orange
-Breaking Strength: 32kN/7100lbs
-Material: Sheave – Aluminum
-58mm / 2.28 inches
-Net weight: 430g/15Oz
-Max. diameter of rope: 0.59 inches or 15mm
-Ball Bearing
-Certification: CE1282 EN363
-Length : 149mm/5.87in
-Width : 83mm/3.27in

Oval Locking Carabiner
-Material: aircraft-grade aluminium alloy (anodized)
-Breaking Strength: 25kN – minor axis: 9 kN – open gate: 9 kN
-Gate opening (d): 21 mm
-Net weight: 80g / 2.82Oz
-Length: 110mm/4.33in
– Width:60mm/2.36in
-Certification(s) : CE 1019 EN 363
Oval, the classic shape for carabiner
1. Symmetrical shape gives the oval carabiner the characteristics of well equalizing loads.
2. When balance of loading is required during operation, oval aluminum locking carabiner is always the right option for you.
3. Keylock nose prevents from rope snagging.
4. Large gate opening of 21mm make carabiner easy to clip and unclip.
5. Large inner space for capacity of holding more other connectors.

30 ± 8mm Eye-to-Eye Prusik Cord:
-Length: 762mm/3inch
-Diameter:8mm / 5/16 inch
-Meterial: Polyester
-Strength: 20kN/4500lb

Assistance in ascending a rope:
-Process capture in hauling/dragging/tensioning System.
-Compared to mechanical grab, Prusik cord is much lighter and more compact, taking little space in your rack.
-It also does almost no damage to host rope and could work in both directions during application.

Note
-Manual measurement, error 1-3cm, depending on the actual situation, please understand;
-Please feel free to contact us if you have any question about the product. We would try our best to solve any problem for you. Wish you have a good shopping experience.
